37
Troubleshooting
Water Wizard (Improper Water Supply)
Troubleshooting
CAUTION!
Only proceed to steps two and three if step one does not correct the problem.
Step 2 Enter Program Mode
Press and hold the enter key for three
seconds to enter program mode. The display
will read “Pro” when program mode is active.
Step 1 Adjust the Manual Supply Valve
Adjust the manual supply valve (refer to Start-Up, Water Wizard). If the recommended water pressure does not
provide enough water, increase the pressure until the desired water supply is achieved. If the recommended
water pressure provides too much water, decrease the water pressure until the desired water supply is
achieved.
Step 3 Adjust the On Time Factor
While in the program menu, use the up and
down keys to navigate through the menu
options until “ont” is displayed.
With “ont” displayed, press the enter key to
access the setting.
With the setting displayed, use the up and down keys
to adjust the setting as needed.
Increase the factor to increase the water supply or
decrease the factor to decrease the water supply.
Press the enter key to save the new on time factor
and return to the program menu.
Step 4 Exit Program Mode
After ten seconds of idle time the controller will automatically exit program mode.
NOTE!
If the water supply is too low, the media will
continuously appear dry.
NOTE!
Changing the on time factor by (1) will change
the water supply by approximately 3%.
NOTE!
If the water supply is too high, the media will be
saturated and excessive water will be draining
from the sump tank.
NOTE!
Some water drainage is desired to keep the media flushed, but it should be minimized to utilize the
Water Wizard.
IMPORTANT!
The enter key must be pressed to save the new
on time factor.
Program Display
On Time Factor Display
