Datacom Systems SS series SPAN - Manual (Page 14)

Datacom Systems Inc
SPAN and Multi-Link Aggregators/Regenerators • USERguide
14
VERSAstream ™ SPAN Series Overview —
The
VERSAstream ™ SPAN aggregator/regenerator provides a single turnkey solution for
24x7 monitoring of redundant, failover, two-link EtherChannel and asymmetric net-
work segments. It provides the ability to monitor one or two SPAN ports simultane-
ously, aggregating the data, and sending a single copy to two, three, four, six or eight
connected network devices.
For example, instead of deploying two network devices connected to two network
taps, simply insert the VERSAstream
™ SPAN aggregator/regenerator into a pair of
SPAN ports, where you want to connect your monitoring or analysis equipment, and
you can instantly begin collecting data from both SPAN ports simultaneously with as
little as one network monitoring tool. It's that simple. No other configuration is nec-
essary.
Asymmetric routing, EtherChannel, and load-balanced environments use multiple
paths to send data, reassembling it as the data reaches its destination. The
VERSAstream
™ SPAN aggregator/regenerator makes monitoring and analyzing mul-
tiple data paths less of a challenge for network managers. The VERSAstream ™
SPAN aggregator/regenerator aggregates the two streams of data it receives, so net-
working professionals can receive all the data they need with as little as one tool and
one trace file.
Redundant networking systems, used in the event of cable or hardware failure, no
longer require more than one device to receive data from both network segments.
Leave your monitoring and analysis tools hooked up 24x7 with no need to manually
switch or move connections. If one network segment, switch, or SPAN port fails or
needs reconfiguration, the VERSAstream
™ SPAN aggregator/regenerator will still be
able to collect data from the secondary segment, so you will never miss a single
packet.
