Chapter 2 Installation Instructions
13
VGA Port (only for 915 G/GV/GL)
The VGA Port is for output to a VGA-compatible device.
1394 Port (optional)
This digital interface supports electronic devices such as digital cameras,
scanners, and printers.
USB 2.0 Ports
These four Universal Serial Bus (USB) ports are available for connecting USB
2.0/1.1 devices.
LAN Port (-L/-K) (optional)
This port allows connection to a Local Area Network (LAN) through a network hub.
Line in, Line out, Microphone Jacks (for -6 models)
When using a 2-channel sound source, the Line out jack is used to connect to
speaker or headphone; the Line in jack connects to an external CD player, tape
player or other audio device. The Microphone jack is used to connect to the
microphone.
When using a 6-channel sound source, connect the front speaker to the green
audio output; connect the surround sound speaker to the blue audio input;
connect the center speaker/subwoofer to the red Microphone input.
Line in, Line out, Microphone, Rear, LEF/CEN, Side Jacks (for -8 models)
When using an 8-channel sound source, connect the front speaker to the green
audio output; connect the rear sound speaker to the black audio input; connect
the center speaker/subwoofer to the orange audio input; connect the side sound
speaker to the grey audio input.
