5
73
5-2 RAID enable in bIoS
1. Enter the BIOS setup by pressing key when boot up.
2. Select the “Integrated Peripherals” from the “Main menu”, then select the
“Onboard
SATA Mode” menu and press to go to the configuration items.
3. Enable RAID function and individual SATA port for hard drive or DVD connection.
4. Press to save the setting then PC will reboot itself.
5-3 Select a RAID Array for Use
When BIOS is restarted, it will display a message asking you to press [Ctrl-F] key to
enter the main menu of Option ROM Utility. Press [Ctrl-F], the Main Menu appears.
Option ROM Utility (c) 2008 Advanced Micro Devices, Inc.
View Drive Assignments. . . . . . [ 1 ]
LD View / LD Define Menu . . . . [ 2 ]
Delete LD Menu . . . . . . . . . . . . [ 3 ]
Controller Configuration . . . . . . [ 4 ]
[ Main Menu ]
Press 1..4 to Select Option [ESC] Exit
[ Keys Available ]
CMOS Setup Utility - Copyright (C) 1985-2011, American Megatrends, Inc.
Integrated Peripherals
► USB Configuration [Press Enter] Help Item
Onboard SATA Controller [Enabled]
Onboard SATA Mode
Onboard Audio Controller [Enabled]
Onboard LAN Controller [Enabled] Native IDE
Onboard LAN Boot ROM [Disabled] RAID
Serial Port1 Address [3F8/IRQ4] AHCI
Serial Port1 Mode [Normal]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
Options
[RAID]
