To adjust the height of the projector, press and hold the elevator
button, raise the projector to the desired height, then release the
button to lock the foot into position. Rotate the leveling knob, if
necessary, to adjust the angle of the projected image.
F
IGURE
17
Adjusting the height of the projector
F
IGURE
18
Leveling knob
elevator button
elevator foot
