R - - - Any sequence starting with a red light indicates that there is
an operational problem with the unit.
RGRR 24 Position deviation (user-set) - The position has exceeded
user-defined error band between command and position.
RGYY 25 Pressure reading out of range - The internal pressure
sensors are either saturated with a pressure over 150 psi or
the sensor has failed. Check supply pressure and if OK
check the pressure sensor board connections and replace
pressure sensor board if necessary.
RGYR 26 Loss of supply pressure - The positioner has determined
that the supply pressure is below 15 psi. Check the supply
pressure and if OK check the pressure sensor board
connections and replace pressure sensor board if
necessary. Minimum recommended supply pressure is
30 psi for proper operation.
RYYY 27 Pilot relay non-motion alert - Check to make sure the air
supply is connected. Also check the internal wiring
harnesses for good connections. This error may be cleared
by briefly pushing the QUICK-CAL button, which will force
the positioner to use the parameters from the last good
calibration. If the positioner still does not operate replace
the pneumatic relay assembly.
RYYR 28 Pilot relay lower position alert - Check to make sure the
air supply is connected. Also check the internal wiring
harnesses for good connections. This error may be cleared
by briefly pushing the QUICK-CAL button, which will force
the positioner to use the parameters from the last good
calibration. If the positioner still does not operate replace
the pneumatic relay assembly.
RYRY 29 Pilot relay upper position alert - Check to make sure the
air supply is connected. Also check the internal wiring
harnesses for good connections. This error may be cleared
by briefly pushing the QUICK-CAL button, which will force
the positioner to use the parameters from the last good
calibration. If the positioner still does not operate replace
the pneumatic relay assembly.
RRGG 30 Watchdog timer timeout (also listed as internal voltage
reference) - This is often caused when intermittent
operation occurs when connecting power. Remove power
and then reconnect to clear. If problem persists it is a bad
electronic assembly, replace.
RRYG 31 Internal temperature alert - The internal positioner
temperature is currently exceeding operational limits of
-40°F (-40°C) or 185°F (85°C).
RRYY 32 Piezo voltage error - Bad electronic assembly, replace.
RRYR 33 Internal voltage reference error - Indicates that the circuit
board is drawing too much power. Check internal wiring and
connectors for electrical shorts – if no shorts are present,
replace the electronic assembly.
RRRY 34 NV RAM checksum error - The checksum of the internal
data was not updated correctly. Cycle power and complete
a QUICK-CAL if error persists. Check internal data to verify
correct settings. If the error still occurs, replace the
electronic assembly.
Version Number Checking
The version number of the embedded code may be
checked at any time except during a calibration by holding
down the up arrow Jog button (
↑
). This will not alter the
operation of the unit other than to change the blink
sequence to three blinks indicating the major version
number. Holding the down arrow Jog button (
↓
) will give
the minor version number without affecting operation.
The version codes are interpreted by adding up the
numbers assigned according to the following table:
Color
First Second Third
blink value blink value blink value
Green 0 0 0
Yellow 9 3 1
Red 18 6 2
For example if holding the up arrow Jog button (
↑
) gave a
G-G-R code, and holding the down arrow Jog button (
↓
)
gave a Y-Y-G code then the resulting version number
would be (0+0+2).(9+3+0) or version 2.12.
SoftTools ™ Configuration and Diagnostic Software
and HART 275/375 Handheld Communicator
Flowserve Corporation has written custom configuration
and diagnostic software for the Logix 3200IQ digital
positioner called SoftTools. This software and the
SoftTools Quick Start Guide are available from a
Flowserve representative.
The Logix 3200IQ digital positioner supports and is
supported by the HART 275/375 Handheld Communicator.
The Device Description (DD) files and the manuals listed
below can be obtained from the HART Communication
Foundation or from your Flowserve representative. For
more information please see the following guides:
• Product Manual for the HART Communicator.
• Logix 3200IQ Digital Positioner with HART 275/375
Communicator User Guide.
Diagnostic features such as the datalog, signature tests,
and ramp tests are performed using the SoftTools
software. Certain calibration features such as loop
calibration, analog output calibration and actuator
pressure sensor calibrations are performed using the
HART 275/375 Handheld Communicator or using
diagnostic software such as SoftTools.
