ELECTRICAL CHARACTERISTICS CURVES
60
65
70
75
80
85
90
95
5 10 15 20 25
OUTPUT CURRENT (A)
E
F
F
ICIE
NCY
(%)
30
36Vin 48Vin 75Vin
0.0
4.0
8.0
12.0
16.0
20.0
24.0
5 10 15 20 25 3
OUTPUT CURRENT(A)
POWER DISSIPATION (W)
0
36Vin 48Vin 75Vin
Figure 1: Efficiency vs. load current for minimum, nominal, and
maximum input voltage at 25
° C.
Figure 2: Power dissipation vs. load current for minimum,
nominal, and maximum input voltage at 25 ° C.
Figure 3: Typical input characteristics at room temperature
(Io=30A)
DS_H48SV05030_08102007 3
