RIGID SHELF INSTALLATION
Shelf support screws
View from under right shelf
This barbecue comes with two (2) rigid shelves that
must be attached. These can be attached using the
four support screws provided and a Phillips-head
screw driver.
1.
Hold the shelf inverted so that one of the corner
holes in the shelf lines up with the appropriate
upper screw hole in the barbecue.
2.
Insert the screw, but do not tighten all the way so
that the shelf can be easily rotated around the fi rst
screw.
3.
Line up the second corner hole in the shelf with
the remaining upper screw hole in the barbecue.
Insert a screw and tighten.
Note: You may lift the edge of the shelf upward
to gain better access during much of the
tightening of this screw.
4.
Finally, insert the bottom screws on the left and right
side of the shelf and securely tighten all screws.
To detach, reverse the process above.
