Installation
For optimal performance of SW8000, read below thoroughly and carefully before start
installation.
1. P RECAUTIONS
Handling
Do not grab the speaker driver unit: SW8000 is packaged in box fitted tight, so your
attention is required when taking speakers out of the box. To avoid the possible damage to
the speaker driver unit, hold both sides of the speaker to pull out of the box. The speaker
driver unit should not be touched to avoid the damage even after it is out of the box.
Recommend to use high quality balanced or unbalanced cable for input connection.
Turn off the power of SW8000 and turn Volume Control of SW8000 to minimum before
connection.
Connection
Connect L&R XLR balanced or TRS balanced / unbalanced input of SW8000 to the
corresponding pre-amp, computer or game console outputs.
2. XLR B ALANCED C ONNECTION
Assure that the power switch of SW8000 is turned off and Volume Control of SW8000 is
turned to minimum. Connect Male side of XLR Balanced Cables to the balanced inputs of
SW8000.
Refer to the following diagram
< Balanced Connection >
Power Cord
XLR Balanced Cables
