Dimplex DFB8842 - Manual (Page 17)

17
Slide glass to the right side of 4.
the fireplace to remove (Figure
7).
remove upper Light Bracket
5.
(Figure 7).
upper bulbs are located in
6.
the upper left and upper right
corners of the fireplace.
unscrew bulbs counter
7.
clockwise.
Insert new bulbs and screw in
8.
clockwise.
re-install upper Light Bracket.
9.
slide front glass back into 10.
position and attach trim.
Purifire™ Filter
The Purifire™ filter supplied in
your fireplace is reusable and
washable. The filter should be
cleaned or replaced on average
once a year. To clean the filter
gently tap filter on a hard surface
to dislodge any loose dirt or
debris, and then clean with water.
no soap or cleaning products are
recommended. The filter size
is 20 x 10 x 1 inches, rated at
mErV 10.
To replace filter:
remove fireplace from mantel. 1.
Filter can be accessed from 2.
Maintenance
the top rear of the unit (Figure
9).
Grasp filter and slide filter
3.
straight up.
replace or clean filter.
4.
!
NOTE: If after market air
filter is used ensure it is
installed according to the
manufacturer’s recommended
instructions.
Figure 9
Purifire™
Filter
glass Cleaning
The glass is cleaned in the factory
during the assembly operation.
During shipment, installation,
handling, etc., the clear door may
collect dust particles, these can
be removed by dusting lightly with
