36 DR

®

SCOUT

FIELD and BRUSH MOWER

CHAPTER 7

PARTS LISTS, SCHEMATIC DIAGRAMS AND WARRANTY

Parts List - Handlebar Assembly

NOTE: Part numbers listed are available through Country Home Products, Inc.

Ref# Part#

Description

01

165361 Handlebar Assy w/Control Panel

02

120301 Screw, 3/8"-16 x 1-1/2", Tri-Lobe

03 Deleted
04

165201 Switch, Snap-In

05

157201 Key, AT2 Ignition Switch

06

139051 Cable, Throttle, 50"

07

150491 Screw, 8-32 x 1/2"

08

165171 Lever, Wheel Clutch, 1"

09

164951 Grip, Handlebar, Ergonomic, 1"

10 164971 Guard,

Switch

11

175381 Cable, Traction Drive,

12

180951 Lever, Blade Engage, w/

Switch

and Harness Adapter

13

164961 Grip, Handlebar, Plain, 1"

14

178991 Cable, Blade Engage, F/B Scout

15 109161 Bolt,

Eye

16

110691 Nut, 5/16"-18

17

110761 Nut, Nylon Lock, 5/16"-18

18

179231 Screw, M6 x 25mm

19

181731 Operator Presence, w/Switch and

Harness adapter


Items Not Illustrated

193591 Assembly and Operation Manual,

F/B Scout

152131 Engine Manual, B&S, All Intek

180941 Wire Harness, B&S

112141 Cable Tie, 7-1/2", black

Safety and Information Labels

162651 Label, Control Panel, F/B Scout

179111 Label, Deck, F/B Scout

173351 Label, Gear Shift, F/B Scout

179251 Label, Shift Lever, F/B Scout

124371 Label, American Flag

127811 Label, Warning, Add Oil

136491 Label,

Danger

136831 Label, Caution Hot Surface

137581

Label,

Check

Oil

148231 Label, Safety Icons
