Chapter 3 BIOS Setup
Chapter 3
Select the Video Device
which will be activated
during POST. This has no
effect if external graphics
present.
Secondary boot display
selection will appear based
on your selection.
VGA modes will be sup-
ported only on primary
display.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
LCD Control
Primary IGFX Boot Display
Active LVDS
[VBIOS Default]
[Disabled]
Chipset
LCD Control
This field configures the LCD control.
When any device is selected in the Primary IGFX Boot Display, it will display the
following information:
Select the Video Device
which will be activated
during POST. This has no
effect if external graphics
present.
Secondary boot display
selection will appear based
on your selection.
VGA modes will be sup-
ported only on primary
display.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
LCD Control
Primary IGFX Boot Display
Secondary IGFX Boot Display
Active LVDS
[CRT]
[None]
[Disabled]
Chipset
Secondary IGFX Boot Display
Selects the secondary display device.
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Active LVDS
Enable or disable the LVDS unction. When enabled, you can select the LCD panel type.
Enable/Disable LVDS
Function
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
LCD Control
Primary IGFX Boot Display
Active LVDS
LCD Panel Type
[VBIOS Default]
[Enabled]
[VBIOS Default]
Chipset
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
LCD Panel Type
Selects LCD panel used by Internal Graphics Device by selecting the appropriate setup
item.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
LCD Control
Primary IGFX Boot Display
Active LVDS
LCD Panel Type
[VBIOS Default]
[Enabled]
[VBIOS Default]
Chipset
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Select LCD panel used by
Internal Graphics Device
by selecting the appropri-
ate setup item.
LCD Panel Type
VBIOS Default
Type 1
Type 2
Type 3
Type 4
Type 5
Type 6
Type 7
Type 8
Type 9
Type 10
Type 11
Type 12
Type 13
Type 14
Type 15
Type 16
640x480
800x600
1024x768
1280x1024
1400x1050 (108MHz)
1400x1050 (122MHz)
1600x1200
1366x768
1680x1050
1920x1200
1440x900
1024x768
1280x1024
1280x800
1920x1080
2048x1536 18 Bit
18 Bit
18 Bit
36 Bit
36 Bit
36 Bit
36 Bit
18 Bit
36 Bit
36 Bit
36 Bit
24 Bit
48 Bit
36 Bit
48 Bit
48 Bit
