Introduction
I/O Connectors
BIOS
Energy Efficient
Design
Damage Free
Intelligence
Temperature
Humidity
PCB
• 1 CompactFlash socket
• 2 connectors for 4 additional external USB 2.0/1.1 ports
• 2 connectors for 2 additional external serial ports
- COM3: RS232 with power
• 1 LVDS LCD panel connector
• 1 LCD/inverter power connector
• 1 DIO connector
• 1 front audio connector for line-out and mic-in jacks
• 1 CD-in internal audio connector
• 1 S/PDIF connector
• 2 Serial ATA connectors
• 1 40-pin IDE connector
• 1 24-pin ATX power connector
• 1 front panel connector
• 1 chassis intrusion connector
• 1 fan connector
• Award BIOS
• 8Mbit SPI BIOS
• Supports ACPI specification 2.0/1.0
• Supports ACPI STR (Suspend to RAM) function
• Wake-On-Events include:
- Wake-On-PS/2 Keyboard/Mouse
- Wake up by PCI card
- PCI Express PME
- USB KB/MS wake up from S3
- Wake-On-Ring
- RTC timer to power-on the system
• Enhanced Intel
® SpeedStep Technology
• AC power failure recovery
• Monitors CPU/system temperature and overheat alarm
• Monitors CPU(V)/3.3V/5V/12V/VBAT(V) voltages and failure
alarm
• Monitors system fan speed and failure alarm
• Read back capability that displays temperature, voltage and
fan speed
• Watchdog timer function
• 0
o C to 60 o C
• 10% to 90%
• Mini-ITX form factor
• 17cm (6.7”) x 17cm (6.7”)
