28
Chapter 2 Hardware Installation
Chapter 2
The lithium ion battery powers the real-time clock and CMOS memory. It is an auxiliary source
of power when the main power is shut off.
Safety Measures
• Danger of explosion if battery incorrectly replaced.
• Replace only with the same or equivalent type recommend by the manufacturer.
• Dispose of used batteries according to local ordinance .
Battery
Battery
SDVO Connector
SDVO
2
1
30
29
The SDVO connector is used to connect the optional SDVO-LVDS daughterboard.
Pins Pin Assignment Pins Pin Assignment
1 Ground 2 DPB_AUXP
3 DPB_LANE0_P 4 DPB_AUXN
5 DPB_LANE0_N 6 SDVO_STALLP
7 Ground 8 SDVO_STALLN
9 DPB_LANE1_P 10 SDVO_INTP
11 DPB_LANE1_N 12 SDVO_INTN
13 Ground 14 PCIE_RST
15 DPB_LANE2_P 16 DPB_CTRLCLK
17 DPB_LANE2_N 18 DPB_CTRLDATA
19 Ground 20 DPB_HPD
21 DPB_LANE3_P 22 GPIO15/SMBCLK
23 DPB_LANE3_N 24 GPIO27/SMBDATA/L_BKLTCTL
25 +3V3 26 +3V3
27 +5V 28 +5V
29 +12V 30 +12V
