Primary Display
Auto When the system boots, it will auto detects the display device.
IGFX When the system boots, it will first initialize the onboard VGA.
PEG When the system boots, it will first initialize the PCI Express x16 graphics card.
Internal Graphics
Keep IGD enabled based on setup options.
Graphics Configuration LCD Control
Select which of IGFX/
PEG/PCI Graphics device
should be primary display
or select SG for Switch-
able Gfx.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Graphics Confi guration
IGFX VBIOS Version
IGfx Frequency
Primary Display
Internal Graphics
GTT Size
Aperture Size
DVMT Pre-Allocated
Gfx Low Power Mode
Graphics Performance Analyzers
 LCD Control
2132
350 MHz
[Auto]
[Auto]
[2MB]
[256M]
[64MB]
[Enabled]
[Disabled]
Chipset
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
ESC: Exit
GTT Size
Select the GTT size 1MB or 2MB
Aperture Size
Select the Aperture size 128MB or 256MB or 512MB
DVMT Pre-Allocated
Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics
Device.
Gfx Low Power Mode
This option is applicable for SFF only. Enable or Disable the Gfx Low Power Mode.
Graphics Performance Analyzers
Enable or disable Intel Graphics Performance Analyzers Counters.
Select the Video Device
which will be activated
during POST. This has no
effect if external graphics
present.
Secondary boot display
selection will appear based
on your selection.
VGA modes will be sup-
ported only on primary
display.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
LCD Control
Primary IGFX Boot Display
Secondary IGFX Boot Display
LCD Panel Type
Active LFP
[CRT]
[LFP]
[VBIOS Default]
[Int-LVDS]
Chipset
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
ESC: Exit
Secondary IGFX Boot Display
Select secondary display device.
LCD Panel Type
Select LCD panel used by Internal Graphics Device by selecting the appropriate
setup item.
Active LFP
Select the active LFP configuration.
No LVDS VBIOS does not enable LVDS.
Int-LVDS VBIOS enables LVDS driver by intergrated encoder.
