www.dfi .com Chapter 4 BIOS Setup
43
Chapter 4
Secondary IGFX Boot Display
Select secondary display device.
LCD Panel Type
Select LCD panel used by Internal Graphics Device by selecting the appropriate setup
item. Please refer to the screen shown below.
LCD Channel Type
Select the LCD Channel Type. The option is dual or single.
LCD Panel Color Depth
Select the color mode of the LCD display. The option is 24-bit or 18-bit.
Select LCD panel used
by Internal Graphics
Device by selecting the
appropriate setup item.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
LCD Control
Primary IGFX Boot Display
Secondary IGFX Boot Display
LCD Panel Type
LCD Channel Type
LCD Panel Color Depth
[CRT]
Chipset
LCD Panel Type
VBIOS Default
Type 1
Type 2
Type 3
Type 4
Type 5
Type 6
Type 7
Type 8
Type 9
Type 10
Type 11
Type 12
Type 13
Type 14
Type 15
Type 16
640x480
800x600
1024x768
1280x1024
1400x1050 (108MHz)
1400x1050 (122MHz)
1600x1200
1366x768
1680x1050
1920x1200
1440x900
1024x768
1280x1024
1280x800
1920x1080
2048x1536 18 Bit
18 Bit
18 Bit
36 Bit
36 Bit
36 Bit
36 Bit
18 Bit
36 Bit
36 Bit
36 Bit
24 Bit
48 Bit
36 Bit
48 Bit
48 Bit


Enter:
+/-:
F1:
F2:
F3:
F4:
ESC:
Select Screen
Select Item
Select
Change Opt.
General Help
Previous Values
Optimized Defaults
Save & Reset
Exit
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Memory Information
Memory RC Version
Memory Frequency
Total Memory
DIMM#1
DIMM#2
CAS Latency (tCL)
Minimum delay time
CAS to RAS (tRCDmin)
Row Precharge (tRPmin)
Active to Precharge (tRASmin)

1.4.0.3
1600 MHz
2048 MB (DDR3)
1024 MB (DDR3)
1024 MB (DDR3)
11
11
11
28
Chipset
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Memory Configuration
This section only display the parameters of memory configuration.
