40 TNMC Maintenance & Troubleshooting
7.8 Power Supplies
Replacing a Power Supply
1. Access the internal components as described in Section ‎7.5.
2. Remove the two screws securing the power supply bracket, and remove it from the
display cabinet.
3. Disconnect all the wires connected to the power supply.
Note: It may be helpful to label the cables to know which cable goes to which
connector when reattaching.
4. Remove the three screws securing the power supply to the bracket, and attach the
new power supply to it.
5. Reconnect all wires, and mount the power supply bracket inside the display cabinet.
7.9 Display Maintenance
Complete a yearly inspection to maintain safe and dependable display operation.
This inspection should address the following issues:
 Loose Hardware: Verify that fasteners, such as bolts and rivets, have not come loose.
Check and tighten or replace fasteners as required.
 Excessive Dust Buildup: It may be necessary to occasionally vacuum the inside of
the display cabinet to remove dust/dirt buildup that may interfere with airflow.
 Corrosion: Check the paint, and look for possible corrosion.
Note: If any of the preceding conditions are discovered, make the necessary repairs or take
corrective action immediately.
7.10 Replacement Parts List
The following tables contain display components that may have to be replaced. Many of the
components within the display itself have attached part number labels.
Part Description Part Number
Indoor TNMC Card 0P-1150-0206
Module; 8x16, Amber 0P-1186-0112
Power Supply; 5V @ 10A, 85-264VAC A-1568
Cable; 18 pos, Ribbon, 6" W-1320
See Section ‎5.9 for information on Daktronics Exchange and Repair and Return program.
