Specifications 5
Section 2: Specifications
The chart on the following pages details all of the mechanical specifications, circuit specifications, and
power requirements for each display in this manual. Models are listed in alphanumeric order.
Notes:
1) All displays require a 120 VAC, 15 A circuit; models with 230 VAC power are also available.
2) Values in [Brackets] indicate scoreboards with Team Name Message Centers (TNMC).
3) Dimensions include corner shrouding and flooring.
4) Optional sheet metal flooring adds 100 lb (45 kg) to total weight.
Model
Dimensions:
Height, Width, Depth
Uncrated
Weight
Watts
Amps
120/230 VAC
Driver #
& Address
BB-2102 4'-2" H, 10'-10" W, 10'-10" D
(1270 mm, 3302 mm, 3302 mm)
780 lb
354 kg
[840 lb
381 kg]
800 W
[1200 W]
6.7 / 3.5 A
[10 / 5.2 A]
A1 17
BB-2104 6'-2" H, 10'-10" W, 10'-10" D
(1880 mm, 3302 mm, 3302 mm)
1020 lb
463 kg
[1080 lb
490 kg]
800 W
[1200 W]
6.7 / 3.5 A
[10 / 5.2 A]
A1 17
BB-2106 4'-2" H, 12'-10" W, 12'-10" D
(1270 mm, 3912 mm, 3912 mm)
900 lb
408 kg
[960 lb
435 kg]
800 W
[1200 W]
6.7 / 3.5 A
[10 / 5.2 A]
A1 17
BB-2108 6'-2" H, 12'-10" W, 12'-10" D
(1880 mm, 3912 mm, 3912 mm)
1200 lb
544 kg
[1260 lb
572 kg]
800 W
[1200 W]
6.7 / 3.5 A
[10 / 5.2 A]
A1 17
BB-2124 6'-2" H, 12'-10" W, 12'-10" D
(1880 mm, 3912 mm, 3912 mm)
1220 lb
553 kg
[1280 lb
581 kg]
1600 W
[2000 W]
13.3 / 7 A
[16.7 / 8.7 A]
A1 17
A2 14
BB-2126 4'-2" H, 12'-10" W, 12'-10" D
(1270 mm, 3912 mm, 3912 mm)
900 lb
408 kg
[960 lb
435 kg]
800 W
[1200 W]
6.7 / 3.5 A
[10 / 5.2 A]
A1 17
