Denon DRA-F100 - Manual (Page 15)

15
ENGLISH
9 PLAYING CDs
About Compact Discs
DIGITAL AUDIO DIGITAL AUDIO
COMPACT
Only discs with the mark shown left can
be played on the DCD-F100.
Disc Remarks
CD
CDV
CD singles
(8 cm discs)
Only the audio part is
played.
Use compact discs that include the mark.
CD’s with special shapes (heart-shaped CD’s, octagonal CD’s
etc.) cannot be played on this set.
Attempting to do so may damage the set. Do not use such
CD’s.
DIGITAL AUDIO DIGITAL AUDIO
COMPACT COMPACT
• For CDVs, only the audio part is played. (The video part is
not played.)
2 Removing discs from their cases
As shown on the diagram,
grasp the outer edge of the
disc with your fingers,
insert a finger in the center
hole, press gently, then lift
the disc out of the case.
2 Loading discs in the disc tray
Be sure to load the disc with
the labelled side facing up.
(Compact discs only play on
one side.) For 8 cm CDs, set
the disc in the sunken section
in the center of the tray.
• The disc tray opens when the OPEN/CLOSE button ( 5 ) is pressed once and closes when it is pressed again.
• When the disc tray is closed, the disc turns automatically for several seconds, then the total number of tracks and
total playing time of that disc appear on the display.
• The disc tray can also be closed by pressing the play button ( 1 ), in which case playback automatically starts from the
first track on the disc (or if tracks are programmed, from the first programmed track).
NOTES:
Do not turn off the power, stop the disc tray by hand or pull on it when
it is moving. Doing so may damage it.
If the headphones’ cord or some other object accidentally gets caught in
the disc tray while it is closing and the disc tray stops, press the
OPEN/CLOSE button (
5 ) again to open the tray and remove the
obstacle.
Do not set objects other than discs on the disc tray. Doing so may
damage it.
Handling the Disc Tray
B
MHz TUNED STERE O AUTO CH
TIMER
B
Normal Playback
ON / STANDBY
OPEN/CLOSE
PERSONAL COMPONENT SYSTEM / COMPACT DISC PLAYER DCD-F100
/ /
3
B
2,4 3 5
1
CD player (DCD-F100)
2 Press the OPEN/CLOSE button (5)
to open the disc tray.
3 Load the CD in the disc tray.
The mark indicates operations which can also be performed on the remote control unit. R
4
Press the OPEN/CLOSE button ( 5 ).
The disc tray closes.
The display appears after several
seconds.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
5 Press the play button ( 1 ).
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 R
Example: Playing a disc containing 15 tracks and with a playing time of 62 minutes, 03 seconds, starting from the
first track
1
Press the SYSTEM power operation
switch (SYSTEM ON/STANDBY) on
the receiver to turn on the system’s
power.
B
MHz TUNED STERE O AUTO CH
TIMER
B
ON / STANDBY
B
MHz TUNED STERE O AUTO CH
TIMER
B
OPEN/CLOSE
OPEN/CLOSE
