CDM-500 Closed Network Satellite Modem Front Panel Operation
Rev. 1.3 6–19
6.7.8 (INFO) MISC (Miscellaneous information)
MISC: IF-LOOP 50 OHMS *
1:1 LINK IDLE ONLINE
This screen shows the following:
•
Test mode
•
IF impedance
•
1:1 link status - if the CRS-100 1:1 module is being used, this shows the
status of the serial link between the two units.
•
Redundancy status - either online or standby (1:1 or 1:N)
IMPORTANT NOTE: If the asterix shown in the top right is present, this means that the
hardware and software support the ‘codeword time-swap’ feature when TSI is selected in
BPSK mode. If the asterix is not shown, the modem does not support this feature. In
general, these are modems prior to S/N 150, and Software prior to V.1.07.
Press Enter to return to the previous menu.
