Site Survey Report, Operator’s Guide, Rev.1
Test Equipment 3-1
3333 33333333 .... ........ T T T T T T T TT T T T eeee eeeeeeee ssss ssssssss tttt tttttttt E E E E E E E EE E E E qqqq qqqqqqqq uuuu uuuuuuuu iiii iiiiiiii pppp pppppppp m m m m m m m m m m m m eeee eeeeeeee nnnn nnnnnnnn tttt tttttttt
The following table identifies the test equipment required to perform a RFI
Survey for either Ku-Band and C-Band surveys.
R R e e q q u u i i r r e e d d T T e e s s t t
E E q q u u i i p p m m e e n n t t
Description Function Model Number
Camera Document selected location for
antenna and indoor equipment Polaroid or equivalent
Spectrum Analyzer C-Band and Ku-Band RFI Survey For C-Band: HP8561E
For Ku-Band: HP8593E
or equivalent
C-Band standard-gain feed horn C-Band RFI Survey Seavey Engineering Associates,
SGA-20 or equivalent
C-Band LNB C-Band RFI Survey Commercial LNB.
Ku-Band standard-gain feed horn Ku-Band RFI Survey Seavey Engineering Associates,
SGA-110 or equivalent
Ku-Band LNB Ku-Band RFI Survey Commercial LNB.
24 VDC Power Supply C-Band and Ku-Band RFI Survey Adequate Power Supply for
selected LNB.
DC Power leads C-Band and Ku-Band RFI Survey 14 AWG wire
Adapter, BNC (male) to Double
Banana Plug C-Band and Ku-Band RFI Survey Pomona, P.N. 1296 or equivalent
Adapter, BNC (female) to SMA
(male) C-Band and Ku-Band RFI Survey Amphenol, P.N. 901-166 or
equivalent
15 VDC Bias Tee (installed at
Spectrum Analyzer input) C-Band and Ku-Band RFI Survey Mini-Circuits, P.N. ZFBT-4R2G
or equivalent
RF Cable C-Band and Ku-Band RFI Survey RG 59/U Type (Trade number
9659) cable with Type F (male) to
SMA (female) or equivalent
Adapter, Type N (male) to SMA
(male) C-Band and Ku-Band RFI Survey Amphenol, P.N. 901-292 or
equivalent
