COOKING HOB WITH GLASS LID
< Do not close the glass lid when the burners or electrical plates are still hot and
when the oven, installed below the cooking hob, is on or still hot.
< Do not rest hot pans or heavy objects on the cooker lid.
< Remove any spillages from the surface of the lid before opening.
CORRECT REPLACEMENT
OF THE BURNERS
< It is very important to check that
the burner flame distributor “F”
and the cap “C” has been correctly
positioned (see figure 14); failure
to do so can cause serious
problems.
< Check that the electrode “S”
(models fitted with electric ignition
- see figure) is always clean to
ensure trouble-free sparking.
< Check that the probe “T” (models
fitted with flame failure device -
see figure) next to each burner is
always clean to ensure correct
operation of the safety valves.
< Both the probe and ignition plug
must be very carefully cleaned.
TRIPLE-RING BURNER
< The triple-ring burner must be correctly positioned (fig. 15); the burner rib must
be enter in the logement as shown by the arrow.
< The burner correctly positioned must not rotate (fig. 16).
< Then position the cap “A” and the ring “B” (fig. 16).
14
Figure 16 Figure 15
C
S
T
F
Figure 14
