2-24
5.5.1.1 Available inputs
Inputs pocket welting machine 100-58
Standard equipment
Input S-No Description Type Connected Remarks
01 01 Clamp at front Initiator Opener X24 Pin 02
04 04 Folder down Initiator Closer X24 Pin 05
13 13 Center knife up Initiator Closer X24 Pin 06
17 17 Clamp back Initiator Opener X24 Pin 03
18 18 Mitre knife down NE Initiator Closer X24 Pin 07
19 19 Mitre knife down NA Initiator Closer X24 Pin 08
20 20 Mitre knifes together Initiator Closer X24 Pin 09
22 22 Foot switch forwards Foot sw. Closer X24 Pin 01
Options
03 03 Folder up Initiator Closer X24 Pin 04
09 09 Dart stretcher up Initiator Closer X27 Pin 20
10 10 Clamp quick adjustment Initiator Closer X27 Pin 21
14 14 Scissor up (home position) Initiator Opener X27 Pin 22 or as folder safety switch
15 15 Scissor cown (cut position) Initiator Closer X27 Pin 23
21 21 Vylene end Photocell Photocell X27 Pin 24
23 23 Foot switch vacuum Foot sw. Closer X24 Pin 12
26 26 Switch reset Foot sw. Closer X24 Pin 13
27 27 Clamp stop photocell Photocell Photocell X24 Pin 11
28 31 Photocell left Photocell Photocell X24 Pin 10
32 Switching single welt jacket/trouser Initiator Closer direct
32 33 Photocell right Photocell Photocell X27 Pin 17
35 35 Thread monitor F&P Photocell X27 Pin 25
36 Zipper transport Micro sw. Closer direct
38 38 Bobbin detector Photocell Photocell X27 Pin 29
39 39 Pocket weltturn dev. down seam start Initiator Closer X27 Pin 30
40 40 Pocket weltturn dev. down seam end Initiator Closer X27 Pin 31
41 41 Pocket welt turn dev. up seam start Initiator Closer X27 Pin 32
