Error 13: Error clamp
position difference between must and real
position (impulses from incremental
Gerber) of the clamp sledge is too
big; clamp sledge blocked removed the blocking partcheck clamp sledge for
easy goingcheck engine piniontighten transport
belt
Error 14: Insertion /
seam length wrong back insertion point is selected;
seam length longer than the di-
stance to the back insertion point program lengths correctly
Error 15: Stamp not up stamp hasn’t reached the top
position after switching off check cylinder, gauge Y20, termination switch
ES19
Error 16: Folder not
straight folder hasn’t reached middle
position within error time check cylinder, gauge Y15, termination switch
ES05
Error 17: Folder not up folder hasn’t reached top position
within error time check cylinder, gauges Y24 Y25, termination
switches ES03 ES04
Error 18: Folder not
down folder hasn’t reached position within
error time check cylinder, gauges Y24 Y25, termination
switches ES03 ES04
Error 19: Folder not
sloping folder hasn’t reached position
‘sloping’ (for picking) within error
time check cylinder, gauge Y15, termination switch
ES06
Error 20: Knifes not
together the mitre knife hasn’t reached start
position before sewing insertion check termination switch ES20check connection
to mitre knife engine (plug)check diodes on
Berger power cardcontinue search acc. to Berger
engine diagnostics
Error 21: Mitre knife not
up mitre knife couldn’t reach top
position within error time check cylinder, gauges Y03 Y48, termination
switch ES13
Error 22: Front mitre
knife not down front mitre knifes (seam end)
couldn’t reach bottom position
within error time check cylinder, gauge Y04, termination switch
ES19
Error 23: Rear mitre
knife not down rear mitre knifes (seam start)
couldn’t reach bottom position
within error time check cylinder, gauge Y04, termination switch
ES18
Error 24: Scissor not up scissor couldn’t reach top position
within error time check cylinder, gauges Y21 Y22, termination
switch ES14
Error 25: Scissor not
down scissor couldn’t reach cutting
position within error time check cylinder, gauges Y21 Y22, termination
switch ES15
Error 26: Pinole not up the pinole for flap turning couldn’t
reach top position within error time check cylinder, gauge Y59, termination switch
ES41
Error 27: Pinole not
down bottom position not reached within
error time check cylinder, gauge Y59, termination switches
ES39 ES40
Error 52: Flap station
not in starting position flap station couldn’t reach starting
position within error time check cylinder, gauge Y17, termination switch
ES07
Error 53: Pocket bag
station not in starting
position Pocket bag supply couldn’t reach
starting position within error time check cylinder, gauges Y18 Y19, termination
switch ES11
Error 54: Station not
locked folder station not locked lock stationcheck termination switch ES02
