Connecting PC
• This product
supports resolution
of VGA, SVGA,
XGA, and SXGA.
• Before connecting
a PC to the PDP,
be sure to adjust
the resolution of
PC.
Connecting PC(15pin D-sub)
40
VIDEO/
DVD SAT TV CATV
DISPLAY
MULTIMEDIA TV/VIDEO
CH
CH
V
O
L
V
O
L
ZO
O
M
+ Z
O
O
M
-
MENU
P
R
E
V
CH
SC
RE
EN
S
IZ
E
MUTE CAPTION
F.F/SLOW PLAY F.R/SLOW
REC STOP PAUSE
PREV OPEN/CLOSE NEXT
MODE
SOUND
MODE STILL
POWER
MTS
ADD/
ERASE SLEEP
Connect the PC to the PDP.
• Prepare the PC cable (D-sub 15pin) and
the PC audio cable(Sold separately).
• Connect the PC(Output) to the
PDP(Input) as shown below.
2
Before connecting to the PDP, set the
resolution of the PC.
• Go to SETUP-CONTROL PANEL-DISPLAY PROPERTIES in Window Screen
of the PC.
• Choose the SETTINGS tab in the DISPLAY Menu.
• In the SETTINGS Menu, select 640 x 480 or 800 x 600.
1
15 PIN D-sub Audio
PC
