Delta Electronics Series E48SB - Manual

Databrief
DB_E48SB_05222008
FEATURES
Š High efficiency: 96.3% @ 12V/20A
Š Size: 58.4mm x 22.8mm x 11.4mm
(2.30”x0.90” x0.45”)
Š Industry standard pin out
Š Fully protected: Input UVLO, OVP, Output
OCP and OTP
Š Parallelable for higher output power
Š 2250V isolation
Š Basic insulation
Š Monotonic startup
Š No minimum load required
Š ISO 9001, TL 9000, ISO 14001, QS9000,
OHSAS18001 certified manufacturing
facility
Š UL/cUL 60950 (US & Canada) Recognized,
and TUV (EN60950) Certified
Š CE mark meets 73/23/EEC and 93/68/EEC
directives
APPLICATIONS
Š Datacom / Networking
Š Wireless Networks
Š Optical Network Equipment
Š Server and Data Storage
Š Industrial/Testing Equipment
OPTIONS
Š Positive On/Off logic
Š Short pin lengths
Š Heatsink available for extended
operation
Š OTP and OCP mode (auto restart or
latch-up)
Delphi Series E48SB, Eighth Brick Bus Converter
DC/DC Power Modules: 48V in, 240W out
The Delphi Series E48SB, Eighth Brick sized, 48V input, single
output, open frame bus converters are the latest offering from a world
leader in power systems technology and manufacturing -- Delta
Electronics, Inc. This product features an input voltage range of 38V to
55V and provides up to 240 watts of power or up to 25A of output current
in an industry standard footprint. This product represents the next
generation of design technology that supports the intermediate bus
architecture to power multiple downstream non-isolated point-of-load
(POL) converters. With creative design technology and optimization of
component placement, these converters possess outstanding electrical
and thermal performance, as well as extremely high reliability under
stressful operating conditions. All modules carry a full set of international
safety approvals. An optional heatsink is available for extreme thermal
requirements.
