Avionics Innovations ICE PCU (Passenger Control Unit) Operation Manual - Manual (Page 7)

5 ICE Operation Manual, P/N 8011-00, Rev A, January 18, 2006
2. When the desired menu item is displayed, rotate the knob to change the
value.
Note: Pushing the knob will move to the next menu item.
To Pause Playback
1. Press the PLAY / PAUSE button.
Press the PLAY / PAUSE button again to resume playback.
To Stop Playback
1. Press the DISP button.
To Eject DVDs
1. Push the DISP Button.
AUX (External Input Mode)
This unit is equipped with an external input mode capable of accepting a low—
level input from another audio device. Devices like an MP3 player or other porta-
ble music device will work for this input. After the unit is turned on, press the SRC
button to change to the external input mode. “AUX” will be displayed on the PCU
display. Use the controls on the external device to set volume.
Note: The PCU volume will adjust the overall volume.
Satellite Operation
After power has been applied to the system, “Avionics Innovations” will display
during the self-test and initiation. The display will then go blank until the PWR
button on the PCU is pressed.
The system will turn on in SAT mode and display the current channel tuned.
Note: “SAT” will not be displayed if the Sirius Satellite Radio (SSR)
unit is not installed.
Note: If Sirius service has not been subscribed to, the unit will only
display and play channel 184 (weather / preview channel).
