ICE Operation Manual, P/N 8011-00, Rev A, January 18, 2006 1
General Information
The purpose of this operation manual is to provide information to ensure proper
operation of this product.
It is the responsibility of those installing this item on or within a specific type or
class of certified aircraft to document and obtain approval for an acceptable in-
stallation from the administrator.
General Description
The ICE system consists of three main components:
• Passenger Control Unit (PCU)
• DVD Player (DVD)
• Remote Satellite receiver (SAT)
• Video Amplifier
The PCU will normally be mounted in an area accessible to the passengers. It
contains all of the controls and display for the system. All of the functions can be
operated from the PCU. There is an infrared remote controller that can control
the most frequently used functions such as volume, etc.
The SAT is mounted in a remote location not necessarily readily accessible to the
passenger. There are no passenger controls on the SAT unit.
The DVD player should be mounted in an area that passengers have access for
changing discs. This can be in a cabinet or entertainment equipment bay. The
only direct passenger operation on the DVD is “Eject” when the PCU is off. When
the system is on, the eject feature is controlled at the PCU.
The Video Amp is a remote-mounted video amp with 2 video inputs and 6 video
outputs. Each of the 6 video outputs is selected between Video 1 or 2 input. Six
individual 12 VDC power supplies at 0.75 amps each.
