Dimplex BF8000ST - Manual (Page 7)

7
Figure 3 Figure 2
Foam
block
Cable
Ties
Front
Glass
Trim
Track
2. Remove the foam block from within the fireplace (Figure 2).
3. Using side cutters or scissors, cut and remove the two (2) cable
ties as shown in Figure 2 and remove the cardboard that protects
the log set.
4. Remove the right hand side trim by removing four (4) Phillips
screws at the side of the fireplace.
5. Place the Front Glass onto the track of the fireplace (Figure 3) and
slide it along the front until it reaches the far left of the unit.
6. Re-attach the right hand trim piece using the four (4) Philips screws
from step 4.
Site Selection and Preparation
This section provides instructions for selecting a location and preparing
the site to install the fireplace into your Dimplex mantel surround.
1. Select a suitable location that is not susceptible to moisture and is
away from drapes, furniture and high traffic.
2. For ease of electrical hook up you may wish to locate the fireplace
near an existing outlet (refer to NOTE 1).
3. Store the fireplace in a safe dry and dust free location.
CAUTION: Clearance for air circulation beneath the fireplace is
provided by two spacers. Do not install fireplace directly on
