12
to be replaced when you notice a dark section of the flame or when
the clarity and detail of the log Ember bed exterior reduces. There
are three (3) bulbs under the Log Set, which generate the flames and
embers, and two (2) bulbs above the log that illuminate the log exterior.
Lower Light Bulb Requirements
Quantity of three (3) clear chandelier or candelabra bulbs with an E-12
(small) socket base, 60 Watt rating. Example: GE 60bC or Philips
60CTC.
Do not exceed 60 Watts per bulb.
Helpful Hints
It is a good idea to replace all light bulbs at one time if they are close to
the end of their rated life. Group replacement will reduce the number
of times you need to open the unit to replace light bulbs.
Replacement:
1. Slide fireplace out of mantel.
2. Lay unit on it’s back for safe removal of front glass.
3. Remove four (4) Phillips screws from the right side of Trim.
4. Remove Trim.
5. Slide glass to right side of fireplace to remove (Figure 7).
Lower
bulbs
Upper
bulbs
Trim
Front
Glass
Log Set
Figure 7
back
Ledge
Log
Ember bed
Rear
Tab
Front
Edge
Side Section
Figure 8
6. Pull the front edge of the plastic Ember bed or plastic grate up and
forward until the rear tab releases from the ledge located at the
bottom of the mirror (Figure 8).
