Argox CP Series - Manual (Page 71)

71
Compact Printer Series - User
’s Manual
Ethernet Interface
The following port complies with Ethernet communication.
Pin Signal
1 Transmit+
2 Transmit-
3 Receive+
4 Reserved
5 Reserved
6 Receive-
7 Reserved
8 Reserved
1 2 3 4 5 6 7
8
