Argox CP Series - Manual (Page 64)

64
Compact Printer Series - User
’s Manual
Utility
Media Type
Roll-feed, die-cut, continuous, fan-fold, tags, ticket in
thermal paper or plain paper and fabric label
Media
Max Width:4.33
”(110mm) Min Width:1”(25.4mm)
Thickness:0.0025”~0.01”(0.0635~0.254mm)
Max roll capacity(OD):5”(127mm) Core size:1”(25.4mm) /
Max roll capacity(OD):4.5”(114.3mm) Core
size:0.5”(12.7mm) (optional) /
Max roll capacity(OD):4.72
”(120mm) Core
size:1
.5”(38.1mm) (optional)
Min Length: 0.79
“(20mm) for rotary cutter option
Ribbon
Ribbon roll
– max OD: 2.6”(67mm)
Ribbon Length: max 300m
Core size
– ID: 1”(25.4mm)
Ribbon Width: 1”~4”, Wax, Wax/Resin, Resin
(Ribbon wound ink-side out or ink-side in)
Dimensions L 273mm x W 225mm x H 186mm
Weight 2.1kg
Power Source
Universal Switching Power
Supply
Input: 100~240V,1.8A,
50-60Hz,
Output: 24VDC, 2.4A Universal Switching Power
Supply
Input: 100~240V,1.5A,
50-60Hz,
Output: 24VDC, 2.91A
Operation
Environment
Operation Temperature: 40

F~100

F (4

C~38

C),
10% ~ 90% non-condensing,
Storage Temperature: -4

F~122

F (-20

C~50

C)
Media Stacker
Optional: CP-2140, CP-2140E, CP-3140L, CP-3140LE
Standard: CP-3140E
Optional Items Cutter, RTC Card, ArgoKee
Agency Listing CE, FCC, cTUVus, CCC, RoHS
