TEChNICAl INFORMATION
SPECIFICATIONS
PRIMARY BATTERY
12V DC/120Ah AGM deep cycle sealed
Dimensions: 16” x 6.85” x 9’17” (407 x 174 x 209mm)
Cycle Charge Life: 500 plus (based on 80% discharge and full
recharge cycles)
PROTECTION FUSES
Battery: MIDI® style bolt-down fuse 32V/200A
AC Input: 10A/250V glass fuse
AC Output: 15A/250V 1 x 1.25 glass ceramic tube
12V DC Output: 15A/125V 5mm x 20mm glass tube
ENERGY CENTER BUDDY #6981
(secondary battery sold separately)
12V120Ah AGM
Used in parallel with the Energy Center will increase working capacity
up to 240Ah.
INVERTER SPECIFICATIONS
MAIN SPECIFICATIONS
•
Output wave form: Pure sine wave
•
Efficiency rating: 90%
•
Output voltage: 120V AC/60Hz (+/-) 5V
•
No load current: 0.4A - 0.8A
•
Continuous power output: 1350 watts
•
Max. power output: 1500 watts
•
Overload power setting: 1800 watts
•
Peak surge power: 2500-3000 watts
PROTECTION CIRCUIT
•
Overvoltage: 15V DC (+/-) 0.2V
•
Low voltage cutoff: 10.5V DC
•
Over temperature: 140ºF (65ºC)
•
Built-in audible alarms and shutdown
•
20A protection fuse
SOLAR/WIND CHARGE CONTROLLER
Rated battery voltage: 12V DC
Charge shutoff voltage: 14.5V DC
Battery overvoltage protection: 15V DC (+/-) 0.2V
Battery overdischarge protection: 10.8V DC
Solar input rating: 30V DC/240 watts max
Wind input rating: 12/24V AC 3-phase/400 watts (50A max)
Dump load control mode: PWM
Wind turbine break current: 34A
DC load #1 and #2 outputs: 12V DC/15A each
AC POWER INPUT
AC power cord: 125V AC/10A rated, 5ft. (1.5m)
AC input: 80-140V AC/3A
AC input fuse: 250V/10A replaceable
3-Stage Charge
•
Charge: 14.5V/15A
•
Float: 13.7V DC
•
Recharge: 12.5V
SOLAR/WIND POWER INPUT
Solar: 30V DC/240 watt max (MC4 connectors)
Wind: 12/24V AC 3-phase/400 watt max (includes 3-phase power
connector for connection to turbine power cord)
POWER OUTPUTS
•
120V AC electrical receptacle: 2-outlets; AC 120/15A each.
(Includes replaceable 15A fuses)
•
12V DC vehicle receptacle: 2-outlets; 12V DC/15A each; 300
watt max combined usage. (Includes replaceable 15A fuses)
•
USB port: 2-ports; 5V DC/2A each
OPERATING TEMPERATURE
32ºF TO 104ºF (0ºC TO 40ºC)
STORAGE TEMPERATURE
-4ºF TO 14ºF (-20ºC TO 35ºC)
DIMENSIONS
31” x 14” x 25.5” (78.74 x 35.56 x 64.77cm)
WEIGHT
170 lbs. (77Kg)
CERTIFICATIONS
FCC Part 15 Reg #STE130823188
CE (EN50178:1997) Reg #STS130823425
