Aervoe 1500-Watt Energy Center - Manual (Page 10)

10
For maximum efficiency and battery life, fully charge before first use, after each use, and every 30 days
during storage to protect battery life and performance. Disconnect all power sources when not using
the Energy Center. The COOLING FAN will run intermittently to prevent overheating during charging.
IMPORTANT: Read all instructions thoroughly including any instructions provided with the solar panel
or wind turbine used.
Three methods of charging are available. Any combination of these methods may be used at the same time.
For optimum battery performance, do not use the power output during charging.
•
120V AC power (included)
• Solar power (Sierra Wave #9590 Solar Collector recommended)
• Wind power (any compatible vertical or horizontal axis turbine)
AC Charging: (included)
1.
Turn the MAIN POWER SWITCH to ON. Charging the unit without it in the ON position will cause
inadequate charging.
2. Connect the included 120V AC POWER CORD to the CHARGING INPUT on the unit and the other
end into a 120V electrical wall outlet.
3. The LED charging indicators on the AC STATUS MONITOR (Fig. 2) will show the progress of
charging.
•
CHARGING (red) = charge in process
• FULLY CHARGED (green) = charge complete
4. Disconnect the AC power cord once charging is complete.
Solar Charging: (solar panel not included)
The Energy Center 1500 can be connected to a 12V solar panel, or multiple panels, with a maximum
combined solar output of 240 watts. Aervoe recommends the Sierra Wave #9590 120-Watt Solar
Collector. Two of these collectors may be connected together to achieve 240 watts.
1.
Follow instructions provided with the solar panel.
2. Position the solar panel in direct sun as described in the instructions provided.
3. Turn MAIN POWER SWITCH to the ON position. Charging the unit without it in the ON position
will cause inadequate charging.
4. Connect the solar panel’s MC4 SOLAR CABLES to the SOLAR INPUT (+) & (-) MC4 connectors
on the Energy Center.
5. Refer to Fig. 1 for solar input status and the Wind & Solar Controller instructions if needed.
6. Disconnect the solar panel once charging is complete or if not in use. It may be left connected if
the Energy Center is also connected to a power output.
wind Charging: (wind turbine not included)
The Wind & Solar Controller allows various styles of wind turbines to charge the Energy Center 1500
- up to 400 watts. An AC 12-24V 3-phase Power Connector is required to connect the turbine to the
Energy Center. This device is included with the Energy Center, but the user is required to wire it to their
turbine according to the manufacturer’s instructions.
(Continued)
• Wind turbines have rotating parts that intermittently start and stop during
operation. Maintain at least a 4 ft clearance from the turbine when operating.
• Disconnect turbine from the Energy Center or other battery before servicing.
• Never operate the turbine when not connected to a Load such as the Energy Center
1500 or other axillary battery as damage could occur to the turbine.
DANGER
ChARGING
