TEKVOX 380-HD Camera - Manual (Page 14)

Specifications
Model HD-380
Sensor
CCD
1/2.5 model, primary color CMOS, 2.1 M
compatible
Minimum Scene
Illumination
6Lux(F1.8/50IRE/TV=1/30sec,
1920×1080movie)
1Lux (F1.8/50IRE/TV=1/8sec,
1920x1080 movie night mode)
White Balance
auto/daylight/cloudy/shade/fluorescent lamp
W (white)/fluorescent lamp N
(Natural)/fluorescent lamp D (daylight) /
tungsten /custom/manual
Gain Control Auto
Back-light
compensation
On/Off
Electronic shutter 1/50-1/4,000S
S/N Ratio
>50dB
Lens
Focus Auto/Manual
Iris Auto/Manual
Zoom
10 Optical Zoom
f = 4.5 – 45.0 mm F1.8 – 2.2
Video Output HD-SDI，HDMI
Video Format
1080P@30，1080P@25，1080P@24，
1080I@60， 1080I@50，720P@60，
720P@50
Communication
RS-485
EIA/RS-232C
Bidirectional
Protocol PELCO_P，PELCO_D，VISCA
Baud Rate 38400/9600 bps (9600 Default)
Presets 64 presets (PELCO) 63 (VISCA)
OSD Menu Supported
Auto Rev P/N/OFF (Support auto reverse)
Pan Speed 0-280 degree per second
Tilt Speed 0-100 degree per second
Pan Rotation Angle (59 degrees continuously
Tilt Rotation Angle 240 degrees
