Signamax 10/100TX to 100FX Industrial PoE Media Converter
User’s Manual
7
Front Panel Display
Status LEDs
LEDs
State
Indication
Power over Ethernet (PoE)
PoE
Steady
Powered Device (PD) is connected.
Off
Powered Device (PD) is disconnected.
10/100BaseT/TX, 100BaseFX/BX
Link/ACT
Steady
A valid network connection established.
Flashing
Transmitting or receiving data.
ACT stands for ACTIVITY.
