Connecting to Your Network
Cable Type & Length
It is necessary to follow the cable specifications below when
connecting the Media Converter to your network. Use
appropriate cables that meet your speed and cabling
requirements.
Cable Specifications
Speed Connector Port Speed
Half/Full
Duplex Cable Max.
Distance
10BaseT RJ-45 10/20 Mbps 2-pair UTP/STP Cat.
3, 4, 5 100 m
100BaseTX RJ-45 100/200
Mbps 2-pair UTP/STP Cat.
5 100 m
100BaseFX SC, ST 200 Mbps
MMF (50 or 62.5μm)
2 km
100BaseFX SC, ST 200 Mbps
SMF (9 or 10μm)
20, 40, or 75
km
100BaseBX SC 200 Mbps
MMF (50 or 62.5μm)
2 or 5 km
100BaseFX SC 200 Mbps
SMF (9 or 10μm)
20 or 40 km
Cabling
 First, ensure the power of the Media Converter and end devices are turned
off.
Always ensure that the power is off before any installation.
 Prepare cable with corresponding connectors for each type of port in use.
 Consult the previous section for cabling requirements based on connectors
and speed.
 Connect one end of the cable to the Media Converter and the other end to
a desired device.
 Once the connections between two end devices are made successfully,
turn on the power and the Media Converter is operational.
