Crossover
Select crossover frequency from which subwoofer handles low range
signal.
[Selectable items]
40Hz 60Hz 80Hz 90Hz 100Hz 110Hz 120Hz 150Hz
200Hz 250Hz
: Select crossover frequency.
Distance FL
Set distance from listening position to front left speaker.
[Variable range] 0ft ~ 60ft
Distance FR
Set distance from listening position to front right speaker.
[Variable range] 0ft ~ 60ft
g ~ A1 2ch Direct/Stereo Custom
Make speaker settings for 2-channel mode playback.
[Display]
1 . S p 2 . I n 3 . O p
E
O p t i o n S e t u p
E
5 2 c h C s t m O F F
E
5 2 c h C s t m O N
E
6 2 c h F L a r g e
E
7 2 c h S W Y e s
E
8 2 c h L F E N o r m
E
9 2 c h F L 1 2 f t
E
1 0 2 c h F R 1 2 f t
E
1 1 2 c h F r e q 8 0
Setting
To change the settings, select “ON”.
[Selectable items]
OFF
: Use the same settings as in “Speaker Setup”.
ON
: Make separate settings for 2-channel mode.
Front
Select front speaker size.
[Selectable items]
Large Small
: Select front speaker size.
Subwoofer Mode
Select low range signal to be reproduced by subwoofer.
[Selectable items]
LFE (Normal) LFE+Main
: Select subwoofer signal.
Subwoofer
Select subwoofer use.
[Selectable items]
Yes No
: Select subwoofer use.
Mute Level
This sets the amount of attenuation of the volume when the mute
mode is set in the main zone.
[Selectable items]
Full
: The sound is cut off entirely.
–40dB
: The sound is attenuated by 40 dB.
–20dB
: The sound is attenuated by 20 dB.
Power On Level
This sets the volume set when the main zone’s power is turned on.
[Selectable items]
Last
: Use the memorized setting from the last session.
– – –
: Always use the muting on condition when power
is turned on.
–80dB ~ +18dB
: Set the volume level when the power is turned on
in units of 1 dB.
Operations (vpage 22)
