Denon AVR-688 - Manual (Page 16)

Get
ting Star
ted
Set
up
Pla
ybac
k
Remot
e Contr
ol
Multi-Zone
Inf
or
mation
Tr
oubleshooting
ENGLISH
47*%&0
065
"6%*0 7*%&0
$0.10/&/57*%&0
: 1 # 1 3
7*%&0
065 065
"6%*0
3 -
065 065
)%.*
065
$0"9*"-
R L
R L
TV/CABLE Tuner
Connect the cables to be used.
TV tuner
When using a optical cable for the digital audio connection, make the settings at “System Setup” – “Input
Setup” – “Digital In Assign” (vpage 25).
Carefully check the left (L) and right (R) channels and the inputs and outputs, and be sure to interconnect
correctly.
Connecting the Recording Components
47*%&0
065
3 - 3 -
065 065 */
"6%*0 7*%&0
*/
"6%*0 7*%&0
*/
R L
R L
R L
R L
Video Cassette Recorder
Connect the cables to be used.
Video cassette recorder
• When recording via the AVR-688, the playback device’s cable must be of the same type as the cable used
to connect the AVR-688’s VCR OUT connector.
Example: TV IN → S-Video cable : VCR OUT → S-Video cable
TV IN → Video cable : VCR OUT → Video cable
• When using a component video cable for the video connection, make the settings at “System Setup” –
“Input Setup” – “Component In Assign” (vpage 26).
or
Connections
