Chapter 1: Product Introduction
Hardware Specifications
CPU Support
▪ 3rd generation Intel ® Core™ rPGA socket type processor
Chipset
▪ Intel ® QM77
▪ Intel ® integrated HD4000 graphic engine
Main Memory
▪ 2x 204-pin SO-DIMM sockets, supports DDR3 1600/1333MHz non-ECC,
un-buffered memory up to 16GB (Single socket max. 8GB)
I/O Interface-Front
▪ 1x power status LED
▪ 1x HDD status LED
▪ 1x power switch
▪ 1x reset switch
▪ 2x USB3.0
▪ 2x DB9 for RS-232
I/O Interface-Rear
▪ +12V DC-in
▪ 3x HDMI
▪ 2x USB3.0
▪ 2x RJ45 with LED for 10/100/1000Mbs Ethernet
▪ 1x SPDIF
▪ 1x Line-in/ 1x Line-out
▪ 3x antenna hole for Wi-Fi and TV tuner
Storage
▪ 1x SATA 2.5” HDD
▪ 1x SATA DOM
Expansion
▪ 1x Mini-PCIe for optional WLAN module
▪ 1x Mini-PCIe for optional TV tuner module
Data Protection
▪ 1x Wafer onboard for TPM module (ver. 1.2), support Intel Trusted
Execution Technology
Construction
▪ Top cover made by aluminum for main heat exchange
▪ Chassis made by steel in black
Dimensions
▪ 294 mm (W) x 198 mm (D) x 52 mm(H) (11.6” x 7.8” x 2.0”)
w/o mounting bracket
Power Supply
▪ 1x External 80W AC/ DC adapter
Input: 100~240VAC
Output: +12VDC
Environment
▪ Operating temperature: 0°C to 40°C
▪ Storage temperature: -20°C to 80°C
▪ Humidity: 10 to 90% (non-condensing)
Certification
▪ CE approval
▪ FCC Class A
Operating System
▪ Windows7 / Windows 8 / XP / WES7 / WES2009 / Linux
