NDiS B322 User Manual
Chapter 3: System Setup
5. The mounting holes on the drive bracket and chassis are used to secure
hard drive to the chassis.
6. Locate the SATA connector and the SATA power connector on the SATA
drive.
SATA Data Connector
SATA Power Connector
SATA Power
Connector
SATA Data
Connector
Mounting
Holes
