Installing a dimm – NEXCOM NDiS B322 User Manual
Page 19
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
6
NDiS B322 User Manual
Chapter 3: System Setup
Installing a DIMM
1. Locate for the DIMM socket on the board.
DIMM
sockets
2. Push the ejector tabs which are at the ends of the socket outward. This
indicates that the socket is unlocked.
Ejector tab
Ejector tab
