Chapter 1: Product Introduction
• LED Size: 12.1”, 4:3
• Resolution: SVGA, 800x600
• Luminance: 350 cd/m2
• Contrast ratio: 300
• LCD color: 262K
• Viewing angle: 50(U), 60(D), 70(L), 70(R)
• Backlight: LED
• Touch screen: Full flat 5-wire resistive
• Touch light transmission: 80%
• Touch interface: USB
• CPU: Intel ® Atom™ D525, 1.8GHz
• BIOS: AMI BIOS
• System chipset: Intel
® ICH8M
• System memory: 1x 204-pin DDR3 SODIMM socket, 1G DDR3 (default),
Supports up to 2GB DDR3 800, Non-ECC and Unbuffered
• SSD: one external locked CF socket by IDE; supports Type I/II
CompactFlash card
• Hard drive bay: optional 2.5” SATA HDD or SATA DOM
• Watchdog timer: Watchdog timeout can be programmable by software
from 1 second to 255 seconds and from 1 minute to 255 minutes (Toler-
ance 15% under room temperature 25
o C)
• H/W status monitor: monitors system temperature and voltage
• Expansion: 2 x mini-PCIe sockets
• NEXCOM Xcare platform system management supported
Rear I/O
• CAN BUS (optional for APPC 1221T only)
• GPIO: 4 x digital in / 4 x digital out (APPC 1221T only)
• COM1: RS232/422/485 (APPC 1221T w/ 2.5kv isolated)
• COM2: RS232/422/485 (APPC 1221T w/ 2.5kv isolated)
• COM3 and COM4: RS232 (APPC 1221T only)
• Ethernet: 2 x RJ45
• 2nd display VGA port: 1 x DB15
• Audio port: 1 x Line-out, 1 x Line-in, 1 x Mic-in
• USB: 4 x USB 2.0
• PS2 keyboard/ mouse
• Power switch
• Reset button
Audio
• AC97 codec: Realtek ALC888
• Audio interface: Line-out, Line-in and Mic-in audio jacks
Ethernet
• LAN chip: Dual Intel 82574L Gigabit LAN
• Ethernet interface: 10/100/1000 Based-Tx Ethernet compatible
Mechanical and Environment
• Color: Pantone black
• IP protection: IP65 front
• Mounting: Panel/Wall/Stand/VESA 100mm x 100mm
• Power input: 12V~30V DC
• Power adapter: Optional AC to DC power adapter (+12V, 60W)
