1. Overview
1.1 Introduction
The FPCB1-M4T-MLA/FPCB1-M4R-MLA series is designed using advanced ASIC and
creative technologies. This series employs multiplexing and de-multiplexing techniques to
transmit and receive DVI high-definition computer video transparently over four multi-mode
optical fibers in all digital signaling with no compression. Because this series utilizes
all-digital, non-compression technology, it is able to transmit signals without distortion;
whereas the analog technology is inherently noisy, with low quality, instable over time and
susceptible to electromagnetic and environmental interference. The
long distance
transmission capability
breaks through the limit that high-definition video signal can only
transmit over short distance by electric cable, therefore, this greatly extends the
transmission distance and the application scope of high definition video signal. As a result,
this enables the high-definition video transmit and share in wide area. DVI interface, built-in
super-automatic equalization and clock re-timing function, makes picture clear and stable,
without any fine jitter. This series
supports the transmitter to read EDID display mode
memory function. Display Mode memory function makes it possible that the host computer
can automatically and correctly configure DVI high definition display mode in connection
with the transmitter in the event that the display is absent of connection or at fault. As a
result of using a unique digital optical encoding technology, unauthorized users can not
access, resulting an improvement of the performance of communication security.
Plug-and-Play design ensures ease of installation and no electrical or optical adjustment is
required. LED indicators are provided for showing operating status.
The FPCB1-M4T-MLA/FPCB1-M4R-MLA series is fully assembled using SMT components
for stability and reliability.
1.2 Technical Specification
DVI
Number of Channels
Transmitter:1 channel of input
Receiver: 1 channel of output
Standard
DVI 1.0
Connector Type
DVI-I
Video display
resolution(Including the largest
display mode for all resolutions)
DVI:UXGA 1600×1200@60HZ
WUXGA 1920×1200@60HZ
HDTV:1080P@60HZ
Sampling Resolution
8/10/12bit
