Ethernet Switch User Manual
Manual-ESUL4-FL1_Series
_
HW-Rev0611B
Copyright © KBC Networks Ltd.
Page 5 of 17
www.kbcnetworks.com
2 Installation
2.1 Package Contents
Ethernet switch fitted with DIN rail mount.
24Vdc PSU (terminal block is connected to 24Vdc power lines)
Wall-mount bracket
Flat head screwdriver
User manual
Please contact you dealer or distributor if a part is missing or damaged.
2.2 Configurations
Products are available in either DIN rail or wall-mount packages, with the following
configurations:
Product Type
DIN Rail
Wall-mount
Multimode
Singlemode
ESUL4-FL1-M2
ESUL4-FL1-S2
