1 Overview
1.1 Introduction
This manual covers the ESUL4-FL1 series. The KBC ESUL4-FL1 products are
high performance, unmanaged, five port industrial Ethernet switches designed
for use in a wide range of operating temperatures in non-environmentally
conditioned, industrial applications. The units have redundant power supply
terminals. All copper ports are automatically configured and the plug-and-play
design provides ease and speed of installation.
1.1.1 ESUL4-FL1
The ESUL4-FL1 provides one uplink, half-duplex/full duplex 100Base-FX fiber
port (either singlemode or multimode) and four 10/100 RJ45 twisted pair
copper ports. Each copper port supports a self-adaptive function, allowing it be
automatically configured to 10Base-T or 100Base-TX, full or half duplex
operation mode. The optical connector is a duplex SC. It is available as either
DIN rail or wall-mount configurations.
