ContRoLs
22
Fuel Shut Off Valve
The fuel shut off valve is located in the fuel line under
the seat. Tilt seat forward for access. The fuel valve is
ON when the valve is parallel to the fuel line. Rotate
the valve ¼ turn clockwise to turn fuel OFF.
8050-010
Fuel shut off valve in the OPEN position.
IMPORTANT INFORMATION
In order to obtain an even cutting height, it is
important that the air pressure is 15 psi in all
tires.
Tracking
If the mower is not tracking straight, check the
air pressure in both rear tires. Recommended air
pressure is 15 psi. (1 bar) Tracking must be checked
on a flat and level concrete or blacktop surface. If the
unit still does not track straight contact your Dixon
workshop for adjustments.
WARNING!
No adjustments or maintenance to be
carried out unless:
the engine stopped •
the ignition key removed •
the parking brake activated •
