ContRoLs
20
Choke Control
The choke control is used for cold starts in order to
provide the engine with a richer fuel mixture.
For cold starts the control should be pushed to the
ON position.
WARNING!
Gasoline is highly flammable. Observe
caution and fill the tank outdoors (see
the safety instruction).
8061-017
Choke control
Blade Switch
In order to engage the mower deck, pull the knob out;
the mower blades are disengaged when the knob is
depressed.
8061-017
Blade switch
Fuses
Fuses are located on the left hand side of the
machine. They are accessed by tilting the seat
forward. They are flat pin fuses of the same type used
in automobiles.
There are two fuses with ratings and functions:
20 A, Primary fuse. •
7.5 A, Mower deck coupling. •
8011-420
Fuses
