ContRoLs
21
Seat Adjustment Lever
The seat can be adjusted lengthways. When making
adjustments, the lever under the front edge of the
seat is moved to the left (as seen by the driver in the
seat), after which the seat can be moved backward or
forward.
8011-441
Lengthways adjustment
Hour Meter
The hour meter displays the total operating time.
It will flash CHG OIL (Change Oil) at 50 hour intervals.
The flash duration is one hour before and one hour
after the interval. The CHG OIL icon will come on
and shut off automatically. The hour meter cannot be
manually reset.
8061-017
Hour meter
Cutting Height Adjuster
The deck cutting height is obtained by pressing the
foot pedal forward to lift the deck. To lower the deck,
apply pressure to the top side of the foot pedal and
allow it to pivot while the lift arm rotates to the rear of
the unit. To stop in the desired cutting position, rotate
the foot pedal down into the notch in the height plate.
The cutting height range is from 1½" (38mm) to 4½"
(114mm) in ¼ (6mm) increments. The heights are
measured from the ground up to the blade tip with the
engine not running.
8050-117
The mower deck’s lifting lever
IMPORTANT INFORMATION
In order to obtain an even cutting height, it
is important that the air pressure in the front
tires is 15 psi and the rear tires is 10 psi.
