Technical Information
24 Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 12
Technical Specifications
Dimensions and
Weight
Length Width Height Weight
28.6 in (728 mm) 9.9 in (252 mm) 21 in (533 mm) 89.0 lbs (40.3 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Electrical Power Supply Type Range Voltage Selection
Switching (internal) 100~240 V, 50/60 Hz Auto-ranging
Parameter 120 V, 60 Hz 230 V, 50 Hz
Consumption 614 W (5 A) 610 W (2.7 A)
Power I/O Input Output
Connectors Hard wired N/A
Cord plug Open ended N/A
Light Source Type Power Current Lifespan
LED 5 W 700~1000 mA 50,000 hours
Color Quantity
Red 44
Green 40
Blue 48
White 24
Amber 24
Photometric Parameter 15 ° Panel 30 ° Panel
Illuminance @ 5 m 1241 Lux 287 Lux
Beam angle 12.2° 21.4°
Field angle 25.5° 39.3°
Thermal Max. External Temperature Cooling System
104° F (40° C)
Fan assisted convection via
Integrated Cooling
Enhancement™
DMX I/O Connectors Connector Type Channel Range
IP Gland Nut N/A 1,3, 4, 5, 6, 7, 9, 10
Ordering Ilumipanel 180 IP Optic 15/30
RGBWA
13180004
